A Deep Dive into JHFOSTER’s Industrial Pneumatic Components
Durable pneumatic components are essential to productivity and operational uptime for today’s manufacturers. As your partner, JHFOSTER offers a full range of pneumatic components built for industrial use, along with professional support, to ensure your pneumatic system produces the clean and efficient air you need to reliably power your equipment.
Our product line up, including FRLs, pneumatic valves, actuators, fittings, couplers and more, along with our engineering expertise, is available to businesses in the Upper Midwest seeking high-quality and reliable pneumatic components for air preparation, automation and motion control applications.
In this blog, we’ll take a closer look at JHFOSTER’s pneumatic components, their applications and the benefits they offer to diverse industries.
What is a Pneumatic System?
Favored for simple designs and cost-effectiveness, pneumatic systems use compressed air to power automated machinery, such as robotic EOAT, packaging and material handling equipment.
Key components of pneumatic systems include:
Intake filters: Intake filters remove contaminants from the air that is being drawn into the compressor.
Air compressor: The air compressor system pressurizes, drys, filters and stores the air until needed.
Filter, regulator, lubricator (FRL) unit: FRLs remove moisture and contaminants at point of use, regulate pressure and provide light lubrication when needed.
Pneumatic valves: Directional control valves and proportional valves control the direction and amount of air entering actuators.
Actuators: These devices convert the energy of the pressurized air into mechanical movement.
How a Pneumatic System Operates
1. Before ambient air is drawn into the compressor, it passes through the inlet air filter to remove contaminants.
2. The air compressor pressurizes the air, which is then cooled, cleaned, dried and stored.
3. When needed, compressed air enters the FRL unit located at the point of use, which filters the air, regulates the pressure and, in some applications, lubricates the air.
4. Pneumatic control valves send compressed air to the actuators.
5. Actuators convert the pressurized air into motion to drive pneumatic equipment, such as robotic end of arm tooling, air-powered tools, packaging machinery, vacuum generators, and other air-operated equipment.
6. Other components, such as fittings, couplers, tubing and hoses, are used to provide leak-free air delivery to pneumatic components, tools and equipment.
The Importance of High-Quality, Reliable Pneumatic Components
The reliability and quality of compressed air are crucial to the performance of the equipment and machines being driven by the pneumatic system, so it’s important that the system is designed with high-quality, high-performing industrial pneumatic components.
JHFOSTER’s pneumatic components deliver the reliability and efficiency that your application demands. With more than 12,000 components and over 80,000 feet of tubing in stock, we are ready to help businesses across the Upper Midwest operate smarter and more effectively.
JHFOSTER’s Range of Pneumatic Components
All our components are manufactured to the highest standards to provide lasting performance in tough industrial applications and are backed by our comprehensive support.
Below are some of our best-performing pneumatic components.
FRL (Filter, Regulator, Lubricator) Components and Air Preparation
FRL units clean, regulate and lubricate compressed air to remove contaminants, maintain stable pressure and reduce friction to extend the lifespan of downstream pneumatic components and connected equipment.
| QUIQMF-50Quincy½”NPT General Purpose Filter | QUI QCF-50Quincy½”NPT Coalescing Filter | QUI QMF-105Quincy1”NPT General Purpose Filter |
| QUI QCF-105Quincy1”NPT Coalescing Filter | NAN GFN0050M1Nano½”NPT General Purpose Filter | NAN GFN0050M01Nano½”NPT Coalescing Filter |
| NAN GFN0105M1Nano½”NPT General Purpose Filter | NAN GFN0105M01Nano½”NPT Coalescing Filter |
| NUM R50R-08GNumatics1”NPT Diaphragm-operated regulator with T-handle for adjustment and 0-125psig range. | JHF 5211B8027/R800-02FRoss1.5”NPT Pilot-operated whole system regulator assembly. | NUM R50W-16G/R800-02Numatics2”NPT Pilot-operated whole system regulator assembly. |
| NUM R50R-04GNumatics1/2”NPT Diaphragm-operated regulator with T-handle for adjustment and 0-125psig range. | NUM 8652AR003FA00G0Aventics3/8” NPT diaphragm-operated regulator with knob for adjustment and 0-125 psig range | NOR R84G-6AK-RMGIMI Norgren¾” NPT diaphragm-operated regulator with knob for adjustment and 0-145 psig range |
| NOR R82G-2AK-RMGIMI Norgren1/4” NPT diaphragm-operated regulator with knob for adjustment and 0-145 psig range |
Safety Valves
Safety valves are automatic, pressure-activated devices that release excess compressed air into the atmosphere when system pressure exceeds preset limits, protecting personnel and equipment.
Directional Control Valves
Directional control valves route compressed air to specific ports to manage the start/stop and direction of airflow to pneumatic actuators.
Proportional Valves
Proportional valves change the output pressure or flow to match that of the input, providing precise response to changes in order to achieve stable flow for repeatable control in automated equipment.
Actuators
A pneumatic actuator converts energy from compressed air into mechanical motion (linear or rotary) to drive pneumatic valves, cylinders or robotic components.
Fittings
High-quality fittings ensure secure, leak-free connections throughout the pneumatic system.
Couplers
Pneumatic couplers act as interfaces so tools and hoses can be changed without shutting off pressure.
| FOS 10-3Foster¼” Male NPT by ¼” body size industrial interchange plug | FOS 3003Foster1/4” female NPT by ¼” body size industrial interchange socket | FOS 11-3Foster¼” Female NPT by ¼” body size industrial interchange plug |
| FOS 3103Foster1/4” Male NPT by ¼” body size industrial interchange socket | FOS 40-4Foster¼” male NPT by 3/8” body size industrial interchange plug | FOS 42-4Foster3/8” male NPT by 3/8” body size industrial interchange plug |
| FOS 5205Foster½” NPT by ½” body size industrial interchange socket | FOS SG3103Foster1/4” Male NPT by ¼” body size industrial interchange socket with sleeve guard |
Flow Controls
Flow controls regulate movement of pressurized air through a pneumatic system.
Vacuum Generators
Pneumatic vacuum generators use compressed air to provide localized vacuum for gripping, lifting or holding objects in industrial and robotic applications
Mufflers
Pneumatic mufflers lower noise levels and prevent the discharge of contaminants from pneumatic systems.
Manifolds
Manifolds are junction blocks that distribute compressed air from a single source to multiple valves, actuators and tools.
Plastic Tubing
Tubing delivers compressed air to actuators, valves and pneumatic tools.
Rubber Hoses
Rubber hose transports pressurized air to pneumatic system components and air-powered tools and equipment.
| FRW 1A-048-10Freelin Wade1/4” OD polyethylene tubing, natural color | FRW 1A-204-01Freelin WadeDescription: ¼” OD nylon tubing, black color | FRW 1A-074-10Freelin Wade3/8” OD polyethylene tubing, natural color |
| FRW 1A-076-10Freelin Wade½” OD polyethylene tubing, natural color | FRW 1A-151-01Freelin Wade14” OD polyurethane tubing, black color | FRWFreelin Wade3/8” by ¼” by 15’ polyurethane recoil, yellow color |
| GOO ¼ x300 OrtacContitech¼” ID by 300 PSI Ortac premium rubber hose | GOO 1/2X200 Blue HorizonContitech½” ID by 200 PSI horizon blue rubber hose | GOO 1/2 x300 OrtacContitech1/2” ID by 300 PSI Ortac premium rubber hose |
Pneumatic Components: The JHFOSTER Advantage
At JHFOSTER we aren’t just a distributor, we are your compressed air and automation partner. Our reliable pneumatic components and solutions are tailored to your application requirements, ensuring optimized results and a pneumatic system that is engineered for efficiency, reliability and high-performance. Whether you’re upgrading an existing pneumatic system or building a new one, contact JHFOSTER today to keep your productivity high and your costs low.
